Nissan Versa I (2006-2012) ign gnd audio shield mic shield mic in + mic in - Wiring diagrams

1 2 3 4 5 6 7 8 BATT 35 36 37 38 39 40 41 42 M CAN (+) M CAN (-) M CAN SHIELD PNK WIRE BLK WIRE BLU WIRE BLUETOOTH ANTENNA BLUETOOTH CONTROL UNIT BRN WIRE CAN-H- CAN-L- COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM CONT 2 CONT 6 SP SIG MIC POWER FUSE 3 FUSE BLOCK (J/B) (UNDER LEFT END OF DASH) GRN WIRE GRY WIRE HOT IN ON OR START IGN GND AUDIO SHIELD MIC SHIELD MIC IN + MIC IN - LT BLU WIRE LT GRN WIRE M CAN JUMPER 1 M CAN +2 M CAN JUMPER 2 M CAN -2 MIC OUT + MIC PWR NCA WIRE OFF ORG/ WIRE PNK WIRE POWER (PHONE/ SEND) SWITCH MODE (PHONE/ END) SWITCH PPL RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT REAR DOOR SPEAKER SEEK SWITCH SPEED OUT 8 STEERING WHEEL AUDIO CONTROL SWITCHES UNIFIED METER CONTROL UNIT VOLUME SWITCH WHT WIRE YEL WIRE YEL/RED WIRE

1 2 3 4 5 6 7 8 BATT 35 36 37 38 39 40 41 42 M CAN (+) M CAN (-) M CAN SHIELD PNK WIRE BLK WIRE BLU WIRE BLUETOOTH ANTENNA BLUETOOTH CONTROL UNIT BRN WIRE CAN-H- CAN-L- COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM CONT 2 CONT 6 SP SIG MIC POWER FUSE 3 FUSE BLOCK (J/B) (UNDER LEFT END OF DASH) GRN WIRE GRY WIRE HOT IN ON OR START IGN GND AUDIO SHIELD MIC SHIELD MIC IN + MIC IN - LT BLU WIRE LT GRN WIRE M CAN JUMPER 1 M CAN +2 M CAN JUMPER 2 M CAN -2 MIC OUT + MIC PWR NCA WIRE OFF ORG/ WIRE PNK WIRE POWER (PHONE/ SEND) SWITCH MODE (PHONE/ END) SWITCH PPL RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT REAR DOOR SPEAKER SEEK SWITCH SPEED OUT 8 STEERING WHEEL AUDIO CONTROL SWITCHES UNIFIED METER CONTROL UNIT VOLUME SWITCH WHT WIRE YEL WIRE YEL/RED WIRE
