Nissan Versa I (2006-2012) encoder power supply encoder gnd 15 2 Wiring diagram

38 11 IGN BAT (F/L) BCM (BODY CONTROL MODULE) (BEHIND RIGHT SIDE OF DASH) BLK WIRE BLU WIRE BRN WIRE CDL LOCK SW CDL UNLOCK SW DN UP DOOR LOCKS SYSTEM DOOR SW (AS) DOOR SW (DR) DOWN DOWN (DR) ENCODER ENCODER POWER SUPPLY ENCODER GND 15 2 ENCODER PULSE A ENCODER PULSE B PNK WIRE FUSE 20 FUSE 6 FUSE BLOCK (J/B) (UNDER LEFT END OF DASH) FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) GND PWR GRN WIRE GRY WIRE HOT AT ALL TIMES FUSIBLE LINK G HOT IN ON OR ACC HOT IN ON OR START LEFT FRONT LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR) LEFT REAR LEFT REAR POWER WINDOW MOTOR (CENTER OF LEFT REAR DOOR) LEFT REAR POWER WINDOW SWITCH LOCK LT BLU WIRE LT GRN WIRE LT PNK WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH ORG/ WIRE PNK PWR WDW PWR SUPPLY (BAT) WIRE PNK WIRE POWER WINDOW LOCK SWITCH PWR WDW PWR SUPPLY (RAP) RED WIRE RIGHT FRONT RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR) RIGHT FRONT POWER WINDOW MOTOR (CENTER OF FRONT PASSENGER'S DOOR) RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH RIGHT REAR RIGHT REAR POWER WINDOW MOTOR (CENTER OF RIGHT REAR DOOR) RIGHT REAR POWER WINDOW SWITCH UNLOCK UP (DR) VIO WIRE WHT WIRE YEL WIRE
