Nissan Titan II facelift (2019-2024) w/ intelligent around view monitor system Wiring diagram
This page shows the only wiring diagram for the component.w/ intelligent around view monitor system, which is found in the car Nissan Titan II facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ intelligent around view monitor system (1 of 1)
ADAS CONTROL UNIT (LOWER CENTER OF DASH)
AROUND VIEW MONITOR CONTROL UNIT
BLK WIRE
BLU WIRE
BLU/WHT WIRE
CAN L
CAN TERMINATOR (CHASSIS CAN COMMUNICATION)
CAN-H
CAN-H PNK CAN-L WIRE
CHASSIS CAN-H
CHASSIS CAN-L
DIAG CAN COMM H
DIAG CAN COMM L
DIAGN CAN COMM H
DIAGN CAN COMM L
DISTANCE SENSOR
FRONT CAMERA UNIT (TOP CENTER OF WINDSHIELD)
GRN WIRE
IGN POW SUPPLY
IT CAN COMM H
IT CAN COMM L
ITS CAN-H
ITS CAN-L
LEFT SIDE RADAR
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT END OF DASH)
RIGHT SIDE RADAR
SONAR CONTROL UNIT (LEFT SIDE OF DASH)
TAN WIRE
V CAN COMM H
V CAN COMM L
W/ INTELLIGENT AROUND VIEW MONITOR SYSTEM
YEL WIRE
Go to component -> Computer data lines circuit (3 of 3) -> W/ INTELLIGENT AROUND VIEW MONITOR SYSTEM
