Nissan Titan II facelift (2019-2024) trip released switch ign Wiring diagram
This page shows the only wiring diagram for the component.trip released switch ign, which is found in the car Nissan Titan II facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trip released switch ign (1 of 1)
AV CONTROL UNIT
BLK WIRE
BLU WIRE
CAN-L CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR MIRROR REMOTE CONTROL SWITCH
FRONT AIR CONTROL
FRONT AUXILIARY INPUT JACKS
FUSE 1
FUSE 13
FUSE 26
FUSE 31
FUSE BLOCK (J/B)
GRY WIRE
HAZARD SWITCH
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
ILL CONT O/P
ILL DOWN SW
ILL UP SW
MANUAL A/C
METER ILLUMINATION
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT END OF DASH)
TRAILER TOW RELAY 1 (RIGHT CENTER OF DASH)
TRIP RELEASED SWITCH IGN
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
VDC OFF SWITCH
WHT WIRE
Go to component -> Instrument illumination circuit (2 of 4) -> TRIP RELEASED SWITCH IGN
