Nissan Titan II facelift (2019-2024) immo st button nat a wiring diagram
This page shows the only wiring diagram for the component.immo st button nat a, which is found in the car Nissan Titan II facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
immo st button nat a wiring diagram (1 of 1)
AUDIO DONGLE
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BUZZER
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DONGLE UNIT (CANADA) (UPPER RIGHT SIDE OF DASH)
FUSE 16
FUSE 31
FUSE BLOCK (J/B)
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
IMMO ST BUTTON ANT B
IMMO ST BUTTON NAT A
NATS ANTENNA AMPLIFIER
PNK WIRE
PPL
RIGHT END OF DASH)
SECURITY
SECURITY IND
SHORT IN PIN IN
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
Go to component -> Immobilizer circuit -> IMMO ST BUTTON NAT A
