Nissan Titan II facelift (2019-2024) hf/vr mic 1 input mic 1 sig Wiring diagrams
This page contains all the electrical diagrams for the component. hf/vr mic 1 input mic 1 sig, in which he is found in the car Nissan Titan II facelift (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hf/vr mic 1 input mic 1 sig (1 of 2)
ACCESSORY RELAY 1
ACCESSORY RELAY 2
AV CONTROL UNIT
BAT BCM FUSE
BAT PWR (F/L)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
CAM COMP+
CAM SHIELD
CAMERA GND
CAMERA V +
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 15
FUSE 25
FUSE 29
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX 2
FUSIBLE LINK N
GRN WIRE
GRN/RED WIRE
HF/VR MIC 1 INPUT MIC 1 SIG
HF/VR MODE
HF/VR SW
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
ILL
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
MIC + MIC LH RH MIC V + MIC GND
MIC -
MIC GND
MIC GND SHIELD MIC V+
MIC LH RH
MIC SIG
MIC VCC
MICROPHONE
NAVIGATION SYSTEM
NAVIGATION SYSTEM (TELEMATICS CIRCUIT)
PNK WIRE
POWER DISTRIBUTION SYSTEM
REAR VIEW CAMERA CIRCUIT
RED WIRE
RED/WHT WIRE
RIGHT END OF DASH)
SHIELD
TCU
TCU TEL IN-
TCU TEL SHIELD
V-BUS
W/ MOONROOF SHIELD
W/ TELEMATICS
W/0 TELEMATICS
W/O MOONROOF
WHT WIRE
Go to component -> Navigation circuit, w/o amplifier (1 of 3) -> HF/VR MIC 1 INPUT MIC 1 SIG
