Nissan Titan II facelift (2019-2024) door unlock sensor switch Wiring diagram

AS DOOR SW BATT BCM FUSE BATT POWER F/L BATTERY SAVER OUT BCM (BODY CONTROL MODULE) (LEFT CENTER OF DASH) BLK WIRE BLU WIRE CAN L CAN-H CARGO LAMP OUT CARGO LAMP SW CARGO LAMP SWITCH COMPUTER DATA LINES SYSTEM CREW CAB DOOR UNLOCK SENSOR SWITCH DR DOOR LOCK STATUS DR DOOR SW FUSE 1 FUSE 16 FUSE 8 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX 2 FUSIBLE LINK N GND 2 GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT KING CAB LEFT FRONT DOOR LOCK ASSEMBLY LEFT FRONT DOOR SWITCH LEFT LOWER REAR DOOR SWITCH LEFT REAR DOOR SWITCH LEFT UPPER REAR DOOR SWITCH LOCK LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE P/W POWER SUPPLY BATT PNK WIRE PNK/BLU WIRE PPL PW LIN RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT END OF DASH) RIGHT FRONT DOOR SWITCH RIGHT LOWER REAR DOOR SWITCH RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH RIGHT REAR DOOR SWITCH RIGHT UPPER REAR DOOR SWITCH RL DOOR SW ROOM LAMP CONT RR DOOR SW SHORT IN PIN INPUT STEP LAMP CONT TAN WIRE UNLOCK WHT WIRE WHT/BLU WIRE
