Nissan Titan II (2015-2019) pnk add pwr rly Wiring diagram
This page shows the only wiring diagram for the component.pnk add pwr rly, which is found in the car Nissan Titan II (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk add pwr rly (1 of 1)
AXLE DISCONNECT DEVICE ACTUATOR
AXLE DISCONNECT DEVICE RELAY
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
CAN-H PNK CAN-L WIRE
COMPUTER DATA LINES SYSTEM
ECU PWR
FR AXLE CTRL
FR AXLE SW
FR AXLE SW OUTPUT
FUSE 30
FUSE 59
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK O
FUSIBLE LINK Y
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN SW
MODE SENSOR
MTR A
MTR B
MTR PWR
ORG/ WIRE
PNK ADD PWR RLY WIRE
PNK WIRE
PPL
PPL MODE SENS INPUT
RANGE 1 SENS INPUT
RANGE 2 SENS INPUT
RANGE SENSOR
RED WIRE
RIGHT END OF DASH)
ROTARY POS
ROTARY POS SENS INPUT
ROTARY POS SENS RETURN
SHIELD
TRANSFER CONTROL UNIT
TRANSFER MOTOR
TRANSFER ROTARY POSITION SENSOR
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> 4wd circuit -> PNK ADD PWR RLY WIRE
