Nissan Titan II (2015-2019) crew cab, king cab w/ occupant classification system Wiring diagram
This page shows the only wiring diagram for the component.crew cab, king cab w/ occupant classification system, which is found in the car Nissan Titan II (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crew cab, king cab w/ occupant classification system (1 of 1)
3 SINGLE CAB W/ OCCUPANT CLASSIFICATION SYSTEM
A/C AUTO AMPLIFIER (AUTOMATIC A/C) (BEHIND A/C SWITCH ASSEMBLY)
AIR BAG DIAGNOSIS SENSOR UNIT
BCM (BODY CONTROL MODULE)
BLU WIRE
CAN L
CAN-H
CREW CAB, KING CAB W/ OCCUPANT CLASSIFICATION SYSTEM
DRIVER SEAT CONTROL UNIT
FRONT AIR CONTROL (MANUAL A/C)
PNK WIRE
RED WIRE
STEERING ANGLE SENSOR
TRANSFER CONTROL UNIT
W/O OCCUPANT CLASSIFICATION SYSTEM
WHT WIRE
Go to component -> Computer data lines circuit (2 of 3) -> CREW CAB, KING CAB W/ OCCUPANT CLASSIFICATION SYSTEM
