Car Wiring Diagrams for Adjustable pedal circuit for Nissan Titan I facelift (2007-2015)

BLK WIRE BLU/BLK WIRE BRN WIRE BWD CIRCUIT BREAKER 2 FUSE, FUSIBLE LINK BOX (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F FWD PEDAL ADJUSTING MOTOR (BEHIND LEFT SIDE OF DASH) GRN WIRE HOT AT ALL TIMES ILLUM LT BLU WIRE PEDAL ADJUSTING SWITCH (LEFT SIDE OF DASH) PPL RED WIRE RED/BLU WIRE WHT WIRE WHT/BLK WIRE
