Nissan Titan I (2003-2006) transfer control unit Wiring diagram
This page shows the only wiring diagram for the component.transfer control unit, which is found in the car Nissan Titan I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transfer control unit (1 of 1)
ACTR SW 1 ACTR SW 2 ACTR SW 3 ACTR SW 4
ACTR SW 2
ACTR SW 3 ACTR SW 4
ATP IND
ATP IND SSOF
ATP-SW
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (BEHIND LOWER LEFT SIDE OF DASH)
FUSE 14
FUSE 53
FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH)
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN SW
IND
INTELLIGENT POWER DISTRIBUTION MODULE (IPDM E/R) (RIGHT REAR OF ENGINE COMPT)
LOCK IND
LOCK LMP
LOCK SW
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLU WIRE
RED WIRE
RED/BLK WIRE
RLY CTRL 2 GND
TRANSFER CONTROL DEVICE ACTR MTR ACTR SW 1
TRANSFER CONTROL UNIT
UNIFIED METER CNTRL UNIT
VIGN VIGN
VIO WIRE
WDS GND MEM B/U
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> 4wd circuit (1 of 2) -> TRANSFER CONTROL UNIT
