Nissan Tiida C11 facelift (2010-2013) yaw rate/ side/decel g sensor Wiring diagram
This page shows the only wiring diagram for the component.yaw rate/ side/decel g sensor, which is found in the car Nissan Tiida C11 facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram yaw rate/ side/decel g sensor (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT
ABS/TCS/VDC CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR
FL (-)
FL IN SOL
FL OUT SOL
FR (-)
FR IN SOL
FR OUT SOL
FUSE 50
FUSE 7
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK F
FUSIBLE LINK K
GND (MTR)
GND SOL -
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
K LINE
LT BLU WIRE
LT GRN WIRE
MOT-
MOTOR BATT
ORG/ WIRE
PNK WIRE
PPL
PPL CAN-H
RED WIRE
RL (+)
RL IN SOL
RL OUT SOL
RR (-)
RR IN SOL
RR OUT SOL
SOL BATT
SOLENOID VALVE
STOP LAMP SW
STOP LAMP SWITCH
VDC OFF
VDC OFF SWITCH
WHT WIRE
YAW RATE/ SIDE/DECEL G SENSOR
YEL WIRE
Go to component -> Anti-lock brakes circuit, w/ traction control (1 of 2) -> YAW RATE/ SIDE/DECEL G SENSOR
