Nissan Tiida C11 facelift (2010-2013) p-shift ind lock ind Wiring diagram
This page shows the only wiring diagram for the component.p-shift ind lock ind, which is found in the car Nissan Tiida C11 facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram p-shift ind lock ind (1 of 1)
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FRONT CONSOLE ANTENNA
FUSE 13
FUSE 3
FUSE BLOCK (J/B)
GND PWR
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
KEY IND
KEY IND (GREEN)
LEFT REAR DOOR LOCK ACTUATOR
LT BLU WIRE
LT GRN WIRE
LT LT
ORG/ WIRE
P-SHIFT IND LOCK IND
PASSENGER SELECT UNLOCK RELAY
PNK WIRE
REAR BUMPER ANTENNA
REAR FLOOR ANTENNA
RED WIRE
RIGHT FRONT DOOR LOCK ASSEMBLY
RIGHT REAR DOOR LOCK ACTUATOR
YEL WIRE
Go to component -> Power door locks circuit, w/ intelligent key unit (2 of 3) -> P-SHIFT IND LOCK IND
