Car Wiring Diagrams for Warning systems circuit for Nissan Teana L33 (2014-2020)

AIR BAG DIAGNOSIS SENSOR UNIT BAT BCM FUSE BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRAKE IND BRN WIRE BUZZER CAN L CAN-H COMBI SW IN 1 COMBI SW IN 2 COMBI SW IN 3 COMBI SW IN 4 COMBI SW IN 5 COMBI SW OUT 1 COMBI SW OUT 2 COMBI SW OUT 3 COMBI SW OUT 4 COMBI SW OUT 5 COMBINATION METER COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH) COMPUTER DATA LINES SYSTEM DR DOOR SW FUSE 1 FUSE 31 FUSE 9 FUSE BLOCK (J/B) GND 2 GND RF A/L GRN WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED LEFT FRONT DOOR SWITCH LEFT SEAT BELT BUCKLE SWITCH LH BUCKLE SW LT GRN WIRE ORG/ WIRE PARKING BRAKE SWITCH PNK WIRE PPL RED WIRE REMOTE KEYLESS ENTRY RECEIVER RF NIMOCO SBR SEAT BELT IND TAN WIRE TIRE PRESSURE IND UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE
