Transmission circuit for Nissan Teana L33 (2014-2020)

2.5L CALIFORNIA 2.5L EXCEPT CALIFORNIA 3.5L BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CAN L CAN-H CAN-H PPL SEC SPEED SENS COMPUTER DATA LINES SYSTEM CONTROL VALVE CVT FLUID TEMPERATURE SENSOR CVT UNIT D RANGE SW DS RANGE SW ECM (NEAR BATTERY) FUSE 46 GRY WIRE HOT W/ IGNITION RELAY 1 ENERGIZED INPUT SPEED SENS IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LINE PRESS SOL VALVE LINE PRESSURE SOLENOID VALVE LT BLU WIRE LT GRN WIRE N RANGE SW ORG/ WIRE PNK BATT PNK BATT WIRE PNK CAN-L WIRE PNK WIRE PPL PRI PRESS SENS PRI PRESS SOLE VALVE PRI SPEED SENS PRIMARY PRESSURE SENSOR PRIMARY PRESSURE SOLENOID VALVE R RANGE SW PPL P RANGE SW RED WIRE SEC PRESS SENS SEC PRESS SOLE VALVE SECONDARY PRESSURE SENSOR SECONDARY PRESSURE SOLENOID VALVE SELECT SOL VALVE SELECT SOLENOID VALVE SENS GND PPL CVT FLUID TEMP SENS SENS PWR SUPPLY TAN WIRE TCC SOLE VALVE TCM (TRANSMISSION CONTROL MODULE) TORQUE CONVERTER CLUTCH SOLENOID VALVE VIGN WHT WIRE YEL WIRE

2.5L BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM CVT SHIFT SELECTOR (OVERDRIVE CONTROL SWITCH) FUSE 13 FUSE 31 FUSE 60 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX GRN WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IGN INPUT SPEED SENSOR (LEFT SIDE OF TRANSMISSION) LT BLU WIRE LT GRN WIRE O/D OFF IND OD OFF/SPORT SW OUTPUT SPEED SENSOR (RIGHT REAR OF TRANSMISSION) PADDLE SHIFTER (SHIFT-DOWN) PADDLE SHIFTER (SHIFT-UP) PNK WIRE PPL PRIMARY SPEED SENSOR (BOTTOM REAR OF TRANSMISSION) RED WIRE RIGHT END OF DASH) SHIFT DOWN SHIFT UP STARTING/ CHARGING SYSTEM TAN WIRE TRANSMISSION RANGE SWITCH UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE YEL WIRE
