Automatic a/c circuit for Nissan Teana L33 (2014-2020)

A/C AUTO AMPLIFIER A/C SWITCH ASSEMBLY ACC RLY OUT ACCESSORY RELAY 2 ACTR (LIN) VACTR ACTR GND AMB SENS (+) AMBIENT SENSOR BCM (BODY CONTROL MODULE) BLK WIRE BLOWER MOTOR BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE CAN-H CAN-L BWR FAN RLY OUT COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM ECV OUT FRONT BLOWER MOTOR RELAY FUSE 14 FUSE 17 FUSE 25 FUSE 27 FUSE 30 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK F FUSIBLE LINK L FUSIBLE LINK N GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGN PPL RX FR IGN USM OUT 1 IN-VEHICLE SENSOR INC SENS PNK INT SENS WIRE INTAKE DOOR MOTOR INTAKE SENSOR IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LEFT AIR MIX DOOR MOTOR LT BLU WIRE LT GRN WIRE MODE DOOR MOTOR P-GND PNK FR FAN PWM WIRE PNK RR DEF F/B WIRE PNK STRG HTR RLY PNK CAN-L WIRE PNK WIRE PPL RED WIRE RIGHT AIR MIX DOOR MOTOR RIGHT END OF DASH) RR DEF SW SEATS SYSTEM SENS GND STRG HTR SW SUN SENS SUNLOAD SENSOR TAN WIRE TX FR WHT WIRE YEL WIRE

2.5L 2.5L CALIFORNIA 2.5L EXCEPT CALIFORNIA 3.5L 3.5L 3.5L PPL A/C COMPRESSOR A/C RELAY BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CLUTCH COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 COOLING FAN RELAY 1 COOLING FAN RELAY 2 COOLING FAN RELAY 3 ECM (NEAR BATTERY) ECT SENS ECV (+) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR FUSE 48 FUSE 53 GND SIG GRN WIRE GRY WIRE HOT AT ALL TIMES IGNITION RELAY 1 IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT BLU WIRE LT GRN WIRE MAGNET MTR FAN RLY HI MTR FAN RLY MID ORG/ WIRE PNK WIRE PPL RED WIRE REFRIGERANT PRESS SENS SENS PWR SPLY REFRIGERANT PRESSURE SENSOR SENS GND TAN WIRE WHT WIRE YEL WIRE
