Car Wiring Diagrams for Charging circuit for Nissan Sentra B18 (2019-2024)

ACTIVE GRILLE SHUTTER BATTERY BATTERY CURRENT SENSOR BATTERY TEMPERATURE SENSOR BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CAN L CAN-H CHARGE IND COMBINATION METER COMPUTER DATA LINES SYSTEM CURRENT SENS CURRENT SENS GND CURRENT SENS SPLY FL BAT 1 FORWARD OF BATTERY) FUSE 47 FUSE BLOCK (J/B) FUSIBLE LINK A FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK E GENERATOR GRN WIRE GRY WIRE HOT W/ IGNITION RELAY-2 ENERGIZED IGN IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LIN COMM LINE LT BLU WIRE NCA WIRE PNK WIRE PPL/BLU WIRE PPL/PNK WIRE RED WIRE STARTER MOTOR TEMP SENS UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
