Radio circuit, w/ bose & 8 inch color display for Nissan Sentra B18 (2019-2024)

AUX AUDIO GND AUX AUDIO L+ AUX AUDIO R+ AUX SHIELD AV CONTROL UNIT BATTERY BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE CAMERA COMP + CAMERA GND CAMERA SHIELD CAMERA V + CAN L CAN-H COMPUTER DATA LINES SYSTEM D - FRONT AUXILIARY INPUT JACKS FRONT AUXILIARY INPUT JACKS CONTROL UNIT FUSE 32 FUSE 38 FUSE 40 FUSE 48 FUSE BLOCK (J/B) GRN WIRE GROUND HF/VR MODE CHANGE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED LT BLU WIRE M CAN-H M CAN-L MIC GND MIC SIG MIC VCC NAVIGATION SYSTEM NAVIGATION SYSTEM (TELEMATICS CIRCUIT) PNK WIRE POWER ECU PPL PPL/BLK WIRE PPL/BLU WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE REAR VIEW CAMERA CIRCUIT RED WIRE RIGHT END OF DASH) SHIELD TCU TEL IN- TCU TEL SHIELD USB D- USB GND USB VBUS V-BUS VBUS VCC W/ TELEMATICS SYSTEM W/O TELEMATICS SYSTEM WHT WIRE YEL WIRE

AMP ON ANT MAIN ANT SHIELD ANT SUB AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY BACK DISPLAY FWD FR SP LH (-) FR SP RH (-) GRN WIRE HF/VR MODE CHANGE LT BLU WIRE LT GRN WIRE MAIN ANT MENU DOWN MENU OK MENU UP MIC GND MIC SIG MIC VCC PNK WIRE PPL PPL/BLU WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PREAMP SHIELD RED WIRE RIGHT END OF DASH) RR SP LH (-) RR SP RH (-) SAT ANT SAT ANT SHIELD SATELLITE ANTENNA (RIGHT REAR OF ROOF) SEEK DOWN SEEK UP SHIELD STEERING SWITCHES TEL ON TEL VR UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) VOLUME DOWN VOLUME UP WHT WIRE WINDOW ANTENNA YEL WIRE

AMP ON BLK WIRE BLU WIRE BOSE SPEAKER AMP (UNDER CENTER OF HAT SHELF) BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FR DR SP LH- FR DR SP RH+ FR LH IN- FR RH IN- FR TWEETER LH- FR TWEETER RH+ GRN WIRE IGN LEFT FRONT DOOR SPEAKER LEFT FRONT TWEETER LEFT REAR DOOR SPEAKER LEFT REAR SPEAKER LT BLU WIRE LT GRN WIRE PNK WIRE PPL PSHELF LH- PSHELF RH- RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT REAR DOOR SPEAKER RIGHT REAR SPEAKER RR DR SP LH+ RR DR SP RH- RR LH IN- RR RH IN- WHT WIRE YEL WIRE
