Nissan Sentra B18 (2019-2024) ambient sensor Wiring diagram
This page shows the only wiring diagram for the component.ambient sensor, which is found in the car Nissan Sentra B18 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ambient sensor (1 of 1)
ABS IND.
AEB IND
AIR BAG IND
AMBIENT SENSOR
BELT IND
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRN WIRE
BUZZER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ECO MODE IND (IF EQUIPPED)
EPS IND
FOG LIGHT IND (IF EQUIPPED)
FUEL GAUGE
FUEL LEVEL SENSOR UNIT, FUEL PUMP
FUSE 32
FUSE 42
FUSE 47
FUSE BLOCK (J/B)
GRN WIRE
HIGH BEAM (BLUE) IND
HIGH BEAM ASSIST (GREEN) IND
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
LEFT TURN IND
LIGHT (GREEN) IND
LT BLU WIRE
MALFUNCTION IND LAMP (MIL)
MASTER WARNING IND (RED/YELLOW) WIRE
METER ILLUMINATION IND
OIL IND
PARKING BRAKE SWITCH
PNK WIRE
POWER TOPS SYSTEM
PPL
PPL/BLU WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/PNK WIRE
PPL/TAN WIRE
RAB OFF IND
RED WIRE
RIGHT TURN IND
SLIP IND
SOUND SYSTEMS
SPEEDOMETER
SPORT IND (CVT)
TACHOMETER
TIRE PRESSURE IND
UNIFIED METER CONTROL UNIT
VDC OFF IND
WASHER FLUID LEVEL SWITCH
WATER TEMPERATURE GAUGE
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> AMBIENT SENSOR
