Car Wiring Diagrams for Headlights circuit for Nissan Sentra B17 facelift (2015-2019)

A/L SENS GND A/L SENS PWR SUPPLY OUTPUT AL SENS INPUT AS DOOR SW BATT (F/L) GND BATT FUSE BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRAKE IND BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH) COMPUTER DATA LINES SYSTEM DR DOOR SW FOG LIGHT IND FUSE 12 FUSE 3 FUSE 8 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK G GND PWR GRN WIRE GRY WIRE HIGH BEAM (BLUE) IND HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IGN INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 LED HEADLAMP-L LED HEADLAMP-R LEFT REAR DOOR SWITCH LT BLU WIRE LT GRN WIRE OPTICAL SENSOR OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 OUTPUT 5 PNK WIRE PPL RED WIRE REMOTE KEYLESS ENTRY RECEIVER RIGHT REAR DOOR SWITCH RL DOOR SW RR DOOR SW TAN WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE YEL WIRE

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FR/FOG/L FRONT FOG LAMP RELAY FUSE 40 FUSE 41 FUSE 42 FUSE 43 FUSE 44 FUSIBLE LINK B FUSIBLE LINK BOX (BATTERY) GND SIG GRN WIRE H/LAMP HI H/LAMP LO HEADLAMP HIGH HEADLAMP HIGH RELAY HEADLAMP LOW HEADLAMP LOW RELAY HOT AT ALL TIMES IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LED HEADLAMP CONTROL MODULE LEFT FRONT COMBINATION LAMP LEFT FRONT DOOR SWITCH LEFT FRONT FOG LAMP PNK WIRE PPL RED WIRE RIGHT FRONT COMBINATION LAMP RIGHT FRONT DOOR SWITCH RIGHT FRONT FOG LAMP W/ HALOGEN HEADLAMPS W/ LED HEADLAMPS WHT WIRE YEL WIRE
