Nissan Sentra B17 facelift (2015-2019) res/ accel switch Wiring diagram
This page shows the only wiring diagram for the component.res/ accel switch, which is found in the car Nissan Sentra B17 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram res/ accel switch (1 of 1)
1.8L
ACCEL/ RES SWITCH
ADAS CONTROL UNIT
ASCD STEERING SWITCH
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE RELAY
BRN WIRE
CAN L
CAN-H
CANCEL SWITCH
COAST/ SET SWITCH
COMPUTER DATA LINES SYSTEM
DISTANCE SWITCH
FUSE 2
FUSE 30
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
ICC SENSOR
ICC STEERING SWITCH
IGN
ITS CAN HIGH
ITS CAN LOW
LT BLU WIRE
MAIN (ON/OFF) SWITCH
ON/OFF MAIN SWITCH CANCEL SWITCH
PNK WIRE
PPL
RED WIRE
RES/ ACCEL SWITCH
RIGHT END OF DASH)
SET/ COAST SWITCH
SPEAKER DRIVE(-)
W/ INTELLIGENT CRUISE CONTROL SYSTEM
W/O INTELLIGENT CRUISE CONTROL SYSTEM
WARNING BUZZER
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 3) -> RES/ ACCEL SWITCH
