Nissan Sentra B17 facelift (2015-2019) lo side eng strt sw ill led output hi side eng sw ill led Wiring diagram

A/L SENS GND A/L SENS PWR SUPPLY OUTPUT ACC SW AL SENS INPUT BATT (F/L) BATT FUSE BATT PWR SPLY BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH) COMPUTER DATA LINES SYSTEM DOWN EARLY PRODUCTION FUSE 12 FUSE 18 FUSE 3 FUSE 4 FUSE 8 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK B FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK G GND GND GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IGN PWR SPLY IGN SW ILL ILL CONT O/P ILL CONT SW - ILL DOWN SW ILL UP SW ILLUMINATION CONTROL SWITCH INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 LATE PRODUCTION LATE PRODUCTION EARLY PRODUCTION LO SIDE ENG STRT SW ILL LED OUTPUT HI SIDE ENG SW ILL LED LT BLU WIRE LT GRN WIRE METER ILLUMINATION OFF OPTICAL SENSOR OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 OUTPUT 5 OUTSIDE ILL O/P CONT SW + PNK WIRE PPL RED WIRE RIGHT END OF DASH) SW GND TAN WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) W/O INTELLIGENT KEY SYSTEM W/ INTELLIGENT KEY SYSTEM WHT WIRE YEL WIRE
