Nissan Sentra B17 facelift (2015-2019) front console power socket Wiring diagram
This page shows the only wiring diagram for the component.front console power socket, which is found in the car Nissan Sentra B17 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front console power socket (1 of 1)
1.8L, 1.6L TURBO
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
ANTI-LOCK BRAKES, DOOR LOCKS, BODY COMPUTER, EXTERIOR LIGHTS, ANTI-THEFT SYSTEMS
BATTERY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CVT
DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
EXTENDED STORAGE SWITCH FUSE 8
FROM ACCESSORY RELAY 1 (DIAGRAM 2 OF 3)
FROM BLOWER RELAY (DIAGRAM 2 OF 3)
FRONT CONSOLE POWER SOCKET
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 28
FUSE 29
FUSE 30
FUSE 55
FUSE 56
FUSE 57
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK A
FUSIBLE LINK B
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK C
FUSIBLE LINK D
FUSIBLE LINK E
FUSIBLE LINK F
FUSIBLE LINK G
FUSIBLE LINK H
FUSIBLE LINK J
FUSIBLE LINK K
FUSIBLE LINK M
GRN WIRE
HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
LT BLU WIRE
LT GRN WIRE
M/T
NCA WIRE
PNK WIRE
PPL
RED WIRE
SEATS SYSTEM
SOUND, NAVIGATION SYSTEMS
STARTING/ CHARGING SYSTEM
STARTING/ CHARGING, DOOR LOCKS, HORNS SYSTEMS
TAN WIRE
TO ACCESSORY RELAY 1 (DIAGRAM 2 OF 3)
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 3)
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TO IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) (DIAGRAM 3 OF 3)
TO PUSH BUTTON IGNITION SWITCH (DIAGRAM 2 OF 3)
TRANSMISSIONS SYSTEM
W/ INTELLIGENT KEY
W/O INTELLIGENT KEY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> FRONT CONSOLE POWER SOCKET
