Nissan Sentra B17 facelift (2015-2019) egr vol ctrl valve position sens exhaust valve timing ctrl position sens Wiring diagram

A/F SENS 1 A/F SENS 1 HEATER ACTUATOR PWR SPLY BLK WIRE BLU WIRE BLU/YEL WIRE BRN WIRE CAMSHAFT POSITION SENS ECM (FORWARD OF BATTERY) ECM GND ECM RELAY (SELF SHUT-OFF) EGR VOL CTRL VALVE MOTOR (-) EGR VOL CTRL VALVE POSITION SENS EXHAUST VALVE TIMING CTRL POSITION SENS EGR VOL CTRL VALVE PWR SPLY EGR VOLUME CONTROL VALVE (-) ELECTRIC WASTEGATE CONTROL ACTUATOR ENG OIL PRESS CTRL SOLENOID VALVE EVAP CANISTER PURGE VOL CTRL SOLENOID VALVE FUEL PUMP RELAY GRN WIRE GRY WIRE HEATED OXYGEN SENS 2 HEATED OXYGEN SENS-2 HEATER IGNITION SIG 1 IGNITION SIG 2 IGNITION SIG 3 IGNITION SIG 4 INTAKE AIR TEMP SENS 2 LT BLU WIRE LT GRN WIRE MULTI-WAY CTRL VALVE POSITION SENS PNK WIRE PNK/BLU WIRE PNP SIG PPL RED WIRE SENS GND SENS PWR SPLY SENSOR 1 SENSOR 2 SHIELD TAN WIRE THROTTLE CONTROL MOTOR THROTTLE CTRL MOTOR (CLOSE) THROTTLE CTRL MOTOR (OPEN) THROTTLE CTRL MOTOR PWR SPLY THROTTLE CTRL MOTOR RELAY THROTTLE POSITION SENS 1 THROTTLE POSITION SENS 2 THROTTLE POSITION SENSOR TURBOCHARGER BYPASS CTRL VALVE ELECTRIC WASTEGATE CTRL WASTEGATE CTRL VALVE POSITION SENS WHT WIRE YEL WIRE
