Nissan Sentra B17 facelift (2015-2019) cruise control, navigation systems Wiring diagram
This page shows the only wiring diagram for the component.cruise control, navigation systems, which is found in the car Nissan Sentra B17 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control, navigation systems (1 of 1)
ACC/ON
ACCESSORY RELAY 1
ACCESSORY RELAY 2 (W/ INTELLIGENT KEY) (BEHIND FUSE BLOCK (J/B)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLOWER RELAY
BLU WIRE
BODY COMPUTERS, DOOR LOCKS, ANTI-THEFT, WARNING, INTERIOR LIGHTS SYSTEMS
BRN WIRE
CRUISE CONTROL, NAVIGATION SYSTEMS
CVT
FROM ACCESSORY RELAY 2 (DIAGRAM 2 OF 3)
FROM BCM (BODY CONTROL MODULE) (DIAGRAM 2 OF 3)
FROM FUSE 14 (DIAGRAM 1 OF 3)
FROM FUSE, FUSIBLE LINK, RELAY BOX (DIAGRAM 1 OF 3)
FUSE 18
FUSE 19
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
IGN 1
IGN 2
IGNITION RELAY 2
IGNITION SWITCH
ILLUMINATION
INSTRUMENT CLUSTER, MIRRORS, SOUND, BODY COMPUTER SYSTEMS
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
M/T
OFF
ORG/ WIRE
PNK WIRE
PPL
PUSH BUTTON IGNITION SWITCH
PUSH SWITCH
PWR
RED WIRE
RIGHT END OF DASH)
RLY OUTPUT
START SW
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO FUSE 15 (DIAGRAM 1 OF 3)
TO FUSE 22 (DIAGRAM 1 OF 3)
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 3)
TO IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) (DIAGRAM 3 OF 3)
W/ INTELLIGENT KEY
W/ INTELLIGENT KEY SYSTEM
W/O INTELLIGENT KEY
W/O INTELLIGENT KEY SYSTEM
WHT WIRE
WIPER/ WASHER SYSTEM
Go to component -> Power distribution circuit (2 of 3) -> CRUISE CONTROL, NAVIGATION SYSTEMS
