Nissan Sentra B17 facelift (2015-2019) automatic a/c manual a/c w/ bose audio 4 3 Wiring diagram
This page shows the only wiring diagram for the component.automatic a/c manual a/c w/ bose audio 4 3, which is found in the car Nissan Sentra B17 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic a/c manual a/c w/ bose audio 4 3 (1 of 1)
6 W/O INTELLIGENT KEY SYSTEM W/ INTELLIGENT KEY SYSTEM 7
A/C SWITCH ASSEMBLY
ASCD STEERING SWITCH
AUDIO UNIT
AUTOMATIC A/C MANUAL A/C W/ BOSE AUDIO 4 3
AV CONTROL UNIT
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CAN L
CAN-H
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR (INDICATOR LAMP)
DIODE 3
DOOR MIRROR REMOTE CONTROL SWITCH
ECO MODE SWITCH
FUSE 37
GRY WIRE
HAZARD SWITCH
HOT AT ALL TIMES
IGNITION RELAY 1
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT FRONT HEATED SEAT SWITCH
MAP LAMP (CONSOLE LAMP)
PNK WIRE
PPL
PUSH BUTTON IGNITION SWITCH
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT HEATED SEAT SWITCH
SPORT MODE SWITCH
STEERING SWITCHES
TAIL LAMP RELAY
TELEMATICS SWITCH
TRUNK LID OPENER SWITCH
VDC OFF SWITCH
W/ INTELLIGENT KEY SYSTEM
W/O BOSE AUDIO 5 W/ DISPLAY AUDIO SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> AUTOMATIC A/C MANUAL A/C W/ BOSE AUDIO 4 3
