Nissan Sentra B16 facelift (2009-2012) seek switch power switch mode switch Wiring diagram
This page shows the only wiring diagram for the component.seek switch power switch mode switch, which is found in the car Nissan Sentra B16 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seek switch power switch mode switch (1 of 1)
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN)
FR LH SP (+) FR LH SP (-) RR SP LH (+) RR SP LH (-) STRG SW A (UP)
FUSE 12
FUSE 22
FUSE 31 (LEFT FRONT OF ENGINE COMPT)
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK BOX
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
LEFT FRONT DOOR SPEAKER
LEFT FRONT TWEETER
LEFT REAR SPEAKER
LT GRN WIRE
LT GRN/BLK WIRE
MODE (PHONE/ END) SWITCH
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER (PHONE/ SEND) SWITCH
PPL
PPL ILL ILL
PPL PNK WIRE
PPL/WHT WIRE
RED WIRE
RED/WHT WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR SPEAKER
ROOF ANTENNA
SEEK SWITCH POWER SWITCH MODE SWITCH
SPEED SIG BAT (BACK UP) GND
STEERING WHEEL AUDIO CONTROL SWITCHES
VOLUME SWITCH
VOLUME SWITCH SEEK SWITCH
W/ BLUETOOTH
W/O BLUETOOTH
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/PPL WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Mid-line radio circuit (1 of 2) -> SEEK SWITCH POWER SWITCH MODE SWITCH
