Nissan Sentra B16 facelift (2009-2012) seek switch Wiring diagrams
This page contains all the electrical diagrams for the component. seek switch, in which he is found in the car Nissan Sentra B16 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram seek switch (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN)
COMPT)
FUSE 12
FUSE 22
FUSE 31
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
LEFT REAR SPEAKER ASSEMBLY
LT GRN WIRE
ORG/ WIRE
PNK WIRE
POWER (PHONE/ SEND) SWITCH MODE (PHONE/ END) SWITCH
PPL
RED/BLU WIRE
RED/YEL WIRE
RIGHT REAR SPEAKER ASSEMBLY
SEEK SWITCH
SPEAKER
STEERING WHEEL AUDIO CONTROL SWITCHES
SUBWOOFER
VOLUME SWITCH
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Navigation circuit, with rockford fosgate (2 of 3) -> SEEK SWITCH
Wiring diagram seek switch (2 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN)
COMPT)
FUSE 12
FUSE 22
FUSE 31
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
LEFT REAR SPEAKER ASSEMBLY
LT GRN WIRE
ORG/ WIRE
PNK WIRE
POWER (PHONE/ SEND) SWITCH MODE (PHONE/ END) SWITCH
PPL
RED/BLU WIRE
RED/YEL WIRE
RIGHT REAR SPEAKER ASSEMBLY
SEEK SWITCH
SPEAKER
STEERING WHEEL AUDIO CONTROL SWITCHES
SUBWOOFER
VOLUME SWITCH
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Premium radio circuit, with rockford fosgate & navigation (2 of 3) -> SEEK SWITCH
