Nissan Sentra B16 facelift (2009-2012) m can shield Wiring diagrams
This page contains all the electrical diagrams for the component. m can shield, in which he is found in the car Nissan Sentra B16 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram m can shield (1 of 6)
45 46 47 48 49 50 51 52 53 USB GND AUDIO L USB D- AUDIO R USB D+ AUDIO GND V BUS
55 56 ANT SIG (GPS) ANT GND (GPS)
57 58 59 ANT ON MAIN ANT
ANTENNA AMP
AUDIO OUT -
AUDIO SHIELD
AV CONTROL UNIT
B(+)
BASE ANTENNA
BLK WIRE
BLU WIRE
BLUETOOTH ANTENNA
BLUETOOTH CONTROL UNIT (UNDER DRIVER'S SEAT)
BRN WIRE
BT ANTENNA
CONT 3
CONT 4
CONT 6
GND CAMERA ON COMP- COMP+ M CAN CHIELD M CAN 1 H M CAN 1 L TEL SHIELD
GPS ANTENNA
GRN WIRE
GRN/YEL WIRE
GRY WIRE
IGN
LT BLU WIRE
M CAN SHIELD
M-CAN
MIC IN -
MIC OUT (+) MIC OUT (-) MIC POWER
MIC POWER
MIC SHIELD
MICROPHONE (CENTER FRONT OF ROOF)
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
PPL
RED WIRE
REVERSE SIGNAL
ROD ANTENNA
SAT ANT
SATELLITE RADIO ANTENNA
SHIELD
SPEED SIG
TEL IN- TEL IN+
USB INTERFACE, AUX JACK
USB SHIELD
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, without rockford fosgate (2 of 2) -> M CAN SHIELD
