Car Wiring Diagrams for Charging circuit for Nissan Sentra B16 (2006-2009)

BATTERY BLK WIRE BLK/GRY WIRE BLK/RED WIRE BRN WIRE CHARGE IND COMBINATION METER FUSE 14 FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE, FUSIBLE FUSE 26 LINK BOX (LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK A FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK E GENERATOR GRY WIRE HOT IN ON OR START NCA WIRE PNK WIRE STARTER MOTOR YEL WIRE
