Courtesy lamps circuit for Nissan Sentra B16 (2006-2009)

11 38 37 39 40 ACC SW IGN SW KEY SW CAN-H CAN-L 13 8 7 DOOR SW (RR) KEY CYL LK SW KEY CYL UNLK SW 27 2 3 PUSH SW CAN-H CAN-L 42 47 48 49 PPL BACK DOOR SW DOOR SW (DR) DOOR SW (RL) LUGG LP OUTPUT 56 63 BAT SAVER ROOM LP OUTPUT 70 57 67 BAT (F/L) BAT (FUSE) GND (PWR) BETWEEN FULL STROKE, N BLK WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM PNK WIRE DOOR SW (AS) FULL STROKE FUSE 12 FUSE 19 (W/O INTELLIGENT KEY) FUSE 21 FUSE 6 FUSE 9 (W/ INTELLIGENT KEY) FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK J GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START INTELLIGENT KEY UNIT (BEHIND RIGHT SIDE OF DASH) INTERIOR ROOM OFF LAMP DOOR ON KEY SWITCH KEY SWITCH, IGNITION KNOB IGNITION KNOB SWITCH KEY SWITCH, KEY LOCK SOLENOID LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR) LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR) LEFT VANITY MIRROR LAMP (IF EQUIPPED) LT BLU WIRE MAP LAMP RIGHT VANITY MIRROR (IF EQUIPPED) LAMP (IF EQUIPPED) ORG/ WIRE PNK WIRE PPL RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR) RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR) SWITCH TRUNK ROOM LAMP TRUNK ROOM LAMP SWITCH UNLOCK SWITCH LOCK SWITCH W/ INTELLIGENT KEY W/O INTELLIGENT KEY WHT WIRE WHT/GRN WIRE YEL WIRE
