Car Wiring Diagrams for Instrument illumination circuit for Nissan Sentra B14 (1994-1999)

39 13 (W/ TACH) (W/O TACH) 40 18 (W/ TACH) (W/O TACH) ASCD MAIN SWITCH (ILLUMINI- NATION) BLK WIRE BLU WIRE COMBINATION METER (ILLUMI- NATION) FAN SWITCH (ILLUMI- NATION) FUSE 36 FUSE BLOCK (J/B) (LEFT SIDE OF I/P) FUSIBLE LINK, FUSE BOX (LEFT FRONT OF ENGINE COMPARTMENT) GRN WIRE HAZARD SWITCH (ILLUMI- NATION) HOT AT ALL TIMES ILLUMINATION CONTROL SWITCH LIGHTING SWITCH MAIN POWER WINDOW, DOOR LOCK SWITCH (ILLUMI- NATION) NCA WIRE OFF RADIO (ILLUMI- NATION) REAR WINDOW DEFOGGER SWITCH (ILLUMINI- NATION) RED WIRE RED/GRN WIRE RED/YEL WIRE YEL WIRE
