Nissan Sentra B14 (1994-1999) tamper switch Wiring diagram
This page shows the only wiring diagram for the component.tamper switch, which is found in the car Nissan Sentra B14 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tamper switch (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
CIRCUIT BREAKER (LEFT KICK PANEL)
FULL STROKE LOCK
FULL STROKE UNLOCK
FUSE
FUSE 39
FUSE 40
FUSE 43
FUSE AND FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT)
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADLIGHTS SYSTEM
HORN RELAY 2 (IN RELAY BOX)
HORNS SYSTEM
HOT AT ALL TIMES
J/C 5 (LEFT SIDE OF DASH)
KEY CYLINDER WITHDRAWN
LEFT DOOR KEY CYLINDER SWITCH
LEFT FRONT DOOR LOCK ACTUATOR
LEFT REAR DOOR LOCK ACTUATOR (4 DOOR)
LEFT REAR DOOR SWITCH
LOCKED
LT GRN/RED WIRE
MID STROKE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT DOOR KEY CYLINDER SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT REAR DOOR LOCK ACTUATOR (4 DOOR)
RIGHT REAR DOOR SWITCH
TAMPER SWITCH
THEFT WARNING HORN (RIGHT SIDE OF ENGINE COMPT)
THEFT WARNING LAMP RELAY (IN RELAY BOX)
UNLOCKED
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Anti-theft circuit (2 of 2) -> TAMPER SWITCH
