1.5l turbo, automatic a/c circuit for Nissan Rogue III (2020-2024)

A/C AMPLIFIER BCM (BODY CONTROL MODULE) BLK WIRE BLOWER MOTOR CONT BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 15 FUSE 30 FUSE 9 FUSE BLOCK (J/B) FUSE SW GRN WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED INTAKE DOOR MOTOR INTAKE SENS INTAKE SENS GND LEFT AIR MIX DOOR MOTOR LIN MODE DOOR MOTOR PNK WIRE POWER SPLY PPL PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/YEL WIRE PWR SPLY REAR AIR MIX DOOR MOTOR RED WIRE RELAY 1 CTRL RELAY 2 CTRL RELAY 3 CTRL RIGHT AIR MIX DOOR MOTOR TAN WIRE WHT WIRE

BLK WIRE BLU WIRE BRN WIRE FRONT BLOWER MOTOR FUSE 104 FUSE 105 FUSE 106 FUSE, FUSIBLE LINK BOX 3 GRN WIRE GRY WIRE HOT AT ALL TIMES IN-VEHICLE SENSOR INTAKE SENSOR LT BLU WIRE LT GRN WIRE PNK WIRE PPL PPL/LT BLU WIRE PTC HEATER (CENTER OF DASH) PTC HEATER RELAY 1 PTC HEATER RELAY 1, BACKUP LAMP RELAY PTC HEATER RELAY 2 PTC HEATER RELAY 2, PTC HEATER RELAY 3 PTC HEATER RELAY 3 RED WIRE SUNLOAD SENSOR TAN WIRE WHT WIRE YEL WIRE

A/C AMP A/C COMPRESSOR A/C SWITCH ASSEMBLY ACC PWR ACC PWR SPLY BLK WIRE BLU WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM ECV CONT ELECTRICAL CONTROL VALVE FUSE 40 FUSE 71 FUSE BLOCK (J/B) FUSIBLE LINK LL GRN WIRE HEATED STRG WHEEL RLY HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY-2 ENERGIZED IGNITION RELAY IN-VEH SENS IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LIN LT BLU WIRE MAGNET CLUTCH VALVE MOD CONT PNK WIRE PPL/BLK WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/PNK WIRE PPL/RED WIRE PPL/YEL WIRE REAR AIR CONTROL SEATS SYSTEM SENS GND SMART FET SPLY GND SUNLOAD SENS TAN WIRE WHT WIRE YEL WIRE

BATT PWR SPLY BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM COOLING FAN CONTROL MODULE 1 COOLING FAN CONTROL MODULE 2 COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 ECM GND ECT SENS 1 ECT SENS 2 ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 FUSE 100 FUSE, FUSIBLE LINK BOX 2 FUSIBLE LINK V FUSIBLE LINK X GRN WIRE GRY WIRE HOT AT ALL TIMES LT GRN WIRE NCA WIRE PRESS SENS PWM PWR PWM SIG RED WIRE REFRIGERANT PRESS SENS REFRIGERANT PRESSURE SENSOR SENS GND SENS PWR SPLY SENS PWR SUPPLY TAN WIRE WHT WIRE
