Nissan Rogue III (2020-2024) w/o bose audio system w/ bose audio system Wiring diagrams

2.5L A/C AMP ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) AIR BAG DIAGNOSIS SENSOR UNIT BCM (BODY CONTROL MODULE) (LEFT END OF DASH) BLU WIRE BRN WIRE CAN L CAN-H CHASSIS CAN COMM 1 H CHASSIS CAN COMM 1 L CHASSIS CAN COMM 2 L CHASSIS CAN COMM 3 H CHASSIS CAN COMM 3 L CHASSIS CAN COMM 4-H CHASSIS CAN COMM 4-L CHASSIS CAN COMM-H CHASSIS CAN COMM-L DRIVETRAIN CAN COMM 1-H DRIVETRAIN CAN COMM 1-L DRIVETRAIN CAN COMM H DRIVETRAIN CAN COMM L ELECTRIC INTAKE VALVE TIMING CONTROL MODULE ENGINE CAN COMM-H ENGINE CAN COMM-L GRN WIRE GRY WIRE INTELLIGENT KEY UNIT LT BLU WIRE PNK WIRE PPL PPL (OR PPL/LT BLU) WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/RED WIRE PPL/WHT WIRE RED WIRE W/O BOSE AUDIO SYSTEM W/ BOSE AUDIO SYSTEM WHT WIRE

ACTIVE NOISE CONTROL UNIT AUTOMATIC BACK DOOR CONTROL MODULE AWD CONTROL UNIT BLU WIRE BOSE SPEAKER AMP BRN WIRE CAN COMM H CAN COMM L CAN L CAN-H CHASSIS CAN COMM-H CHASSIS CAN COMM-L DRIVER SEAT CONTROL UNIT ELECTRIC SHIFT CONTROL MODULE GRN WIRE GRY WIRE HEAD UP DISPLAY UNIT IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT BLU WIRE PNK WIRE POWER STEERING CONTROL MODULE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/RED WIRE RED WIRE STEERING ANGLE SENSOR W/O BOSE AUDIO SYSTEM W/ BOSE AUDIO SYSTEM WHT WIRE
