Nissan Rogue III (2020-2024) w/ 7 inch information display Wiring diagrams
This page contains all the electrical diagrams for the component. w/ 7 inch information display, in which he is found in the car Nissan Rogue III (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ 7 inch information display (1 of 2)
AM-FM MAIN
ANTENNA AMP
ANTENNA BASE
AV CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FRONT LH (-)
FRONT RH (-)
GRN WIRE
GROUND
GRY WIRE
IGN SIGNAL
LT BLU WIRE
LT GRN WIRE
LVDS
NAVIGATION SYSTEM
NAVIGATION SYSTEM (TELEMATICS CIRCUIT)
NCA WIRE
PNK WIRE
PPL
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
REAR LH (+)
REAR RH (+)
RED WIRE
SATELLITE ANT SIG
SATELLITE ANTENNA
SHIELD
SIGNAL (H)
SIGNAL (L)
SIGNAL A
SIGNAL B
SPIRAL CABLE
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
USB D+ SIG
USB GND
V BUS SIG
W/ 7 INCH INFORMATION DISPLAY
W/ TFT METER
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, w/o bose (2 of 5) -> W/ 7 INCH INFORMATION DISPLAY
Wiring diagram w/ 7 inch information display (2 of 2)
AM-FM MAIN
ANTENNA AMP
ANTENNA BASE
AV CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FRONT LH (-)
FRONT RH (-)
GRN WIRE
GROUND
GRY WIRE
IGN SIGNAL
LT BLU WIRE
LT GRN WIRE
LVDS
NAVIGATION SYSTEM
NAVIGATION SYSTEM (TELEMATICS CIRCUIT)
NCA WIRE
PNK WIRE
PPL
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
REAR LH (+)
REAR RH (+)
RED WIRE
SATELLITE ANT SIG
SATELLITE ANTENNA
SHIELD
SIGNAL (H)
SIGNAL (L)
SIGNAL A
SIGNAL B
SPIRAL CABLE
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
USB D+ SIG
USB GND
V BUS SIG
W/ 7 INCH INFORMATION DISPLAY
W/ TFT METER
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, w/o bose (2 of 5) -> W/ 7 INCH INFORMATION DISPLAY
