Nissan Rogue III (2020-2024) turn lh ind Wiring diagram
This page shows the only wiring diagram for the component.turn lh ind, which is found in the car Nissan Rogue III (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn lh ind (1 of 1)
ABS IND.
AEB OFF IND
AIR BAG IND
AMBIENT SENSOR
BELT IND
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BSW WARNING IND
BUZZER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
E-PARK BRAKE IND
EPS IND
FOG LIGHT IND
FUEL GAUGE
FUEL LEVEL SENSOR UNIT (SUB)
FUEL LEVEL SENSOR UNIT, FUEL PUMP
FUEL LEVEL SENSOR UNIT/ FUEL PUMP, FPCM
FUSE 15
FUSE 29
FUSE 40
FUSE 6
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HI BEAM (BLUE) IND
HIGH BEAM ASSIST (GREEN) IND
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY 1 ENERGIZED
LIGHT (GREEN) IND
LT BLU WIRE
MALFUNCTION IND LAMP (MIL)
MASTER WARNING IND (RED/YELLOW) WIRE
METER ILLUMINATION IND
METER SPEAKER
OIL LEVEL IND
OIL PRESSURE IND
PNK WIRE
POSITION LIGHT (GREEN) IND
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
REAR AEB OFF IND
RED WIRE
SHIELD
SLIP IND
SOUND SYSTEMS
SPEEDOMETER
TACHOMETER
TAN WIRE
TIRE PRESSURE IND
TURN LH IND
TURN RH IND
UNIFIED METER CONTROL UNIT
VDC OFF IND
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WASHER FLUID LEVEL SWITCH
WATER TEMPERATURE GAUGE
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> TURN LH IND
