Nissan Rogue III (2020-2024) steering vibration motor Wiring diagrams
This page contains all the electrical diagrams for the component. steering vibration motor, in which he is found in the car Nissan Rogue III (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
steering vibration motor wiring diagram (1 of 3)
ACCEL/ RES SWITCH
ASCD STEERING SWITCH
BLK WIRE
BRN WIRE
CANCEL SWITCH
COAST/ SET SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE ON/OFF SWITCH
DISTANCE SWITCH
DRIVETRAIN CAN COMM H
DRIVETRAIN CAN COMM L
FUSE 73
GRY WIRE
HOT W/ IGNITION RELAY ENERGIZED
ICC STEERING SWITCH
IGNITION
IGNITION PWR SUPPLY
INPUT SPD SENS
INPUT SPEED SENSOR
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT GRN WIRE
ON/OFF (MAIN) SWITCH
OUTPUT SPD SENS
OUTPUT SPEED SENSOR
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/RED WIRE
PPL/WHT WIRE
PRIMARY SPD SENS
PRIMARY SPEED SENSOR
PROPILOT ASSIST MAIN SWITCH
PROPILOT ASSIST STEERING SWITCH
RED WIRE
RES/+ SWITCH
SET SWITCH
SPD SENS
SPIRAL CABLE
STEERING VIBRATION MOTOR
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
W/ INTELLIGENT CRUISE CONTROL SYSTEM
W/ PROPILOT ASSIST
W/O INTELLIGENT CRUISE CONTROL SYSTEM
Go to component -> 1.5l turbo, cruise control circuit (2 of 3) -> STEERING VIBRATION MOTOR
steering vibration motor wiring diagram (2 of 3)
ADAS CONTROL UNIT 2 (UNDER CENTER CONSOLE)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISTANCE SENSOR
ETHERNET
FRONT CAMERA UNIT
FUSE 40
FUSE 9
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY 1 ENERGIZED
IGN
IGN POWER SUPPLY
ITS CAN COMM L
ITS CAN COMM-H
ITS CAN-H
ITS CAN-L
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL/BLK WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/PNK WIRE
PPL/WHT WIRE
RED WIRE
SHIELD
SIG
SIG GND
STEERING ASSIST
STEERING ASSIST SWITCH
STEERING VIBRATION MOTOR
SW SIGNAL
WHT WIRE
YEL WIRE
Go to component -> 1.5l turbo, cruise control circuit (3 of 3) -> STEERING VIBRATION MOTOR
steering vibration motor wiring diagram (3 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
BSW IND SIG
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVETRAIN CAN COM-H
DRIVETRAIN CAN COM-L
GRY WIRE
IGN PWR SPLY
ITS CAN COM-H
ITS CAN COM-L
LEFT BSW IND
LEFT DOOR MIRROR
LEFT SIDE RADAR (BEHIND LEFT END OF REAR BUMPER)
LT BLU WIRE
LT GRN WIRE
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RED WIRE
RIGHT BSW IND
RIGHT DOOR MIRROR
RIGHT SIDE RADAR (BEHIND RIGHT END OF REAR BUMPER)
SPIRAL CABLE
STEERING ASSIST SWITCH
STEERING VIBRATION MOTOR
SWITCHING SIG
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ FULL TFT METER W/ 7 INCH INFORMATION DISPLAY METER
W/ MEMORY
W/O MEMORY
Go to component -> Driver assistance system circuit (2 of 2) -> STEERING VIBRATION MOTOR
