Nissan Rogue III (2020-2024) steering vib motor sig Wiring diagram
This page shows the only wiring diagram for the component.steering vib motor sig, which is found in the car Nissan Rogue III (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering vib motor sig (1 of 1)
ADAS CONTROL UNIT 2 (UNDER CENTER CONSOLE)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA
COMPUTER DATA LINES SYSTEM
DISTANCE SENSOR (BEHIND CENTER OF FRONT GRILLE)
ETHERNET
FRONT CAMERA UNIT (TOP CENTER OF WINDSHIELD)
FUSE 40
FUSE 9
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
HOT W/ IGNITION RELAY 1 ENERGIZED
IGN PWR SPLY
ITS CAN COM-H
ITS CAN COM-L
LINES SYSTEM
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/PNK WIRE
RED WIRE
SHIELD
STEERING ASSIST SW SIG
STEERING VIB MOTOR SIG
STEERING VIB MOTOR SIG GND
WHT WIRE
YEL WIRE
Go to component -> Driver assistance system circuit (1 of 2) -> STEERING VIB MOTOR SIG
