Nissan Rogue III (2020-2024) right instrument panel speaker shield Wiring diagram
This page shows the only wiring diagram for the component.right instrument panel speaker shield, which is found in the car Nissan Rogue III (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right instrument panel speaker shield (1 of 1)
A/C AMP
AUTO ANTI-DAZZLING INSIDE MIRROR
AUTOMATIC BACK DOOR SWITCH
AV CONTROL UNIT
BLK WIRE
BLU WIRE
COMBINATION METER
DATA LINK CONNECTOR
ELECTRIC SHIFT SELECTOR
FRONT CAMERA UNIT
FRONT PASSENGER AIR BAG OFF INDICATOR
HEAD-UP DISPLAY SWITCH
INTELLIGENT KEY UNIT
LEFT ACCESSORY PRE-WIRE
LEFT INSTRUMENT PANEL SPEAKER SHIELD
LEFT PERSONAL LAMP
LEFT VANITY MIRROR LAMP
LUGGAGE ROOM LAMP
MAP LAMP ASSEMBLY
MOONROOF SWITCH ASSEMBLY
NCA WIRE
PNK WIRE
PPL/BLK WIRE
PUSH BUTTON IGNITION SWITCH
REAR USB CHARGE PORT
RIGHT ACCESSORY PRE-WIRE
RIGHT INSTRUMENT PANEL SPEAKER SHIELD
RIGHT PERSONAL LAMP
RIGHT VANITY MIRROR LAMP
ROOM LAMP
SHIELD
SPIRAL CABLE
STEERING ANGLE SENSOR
STEERING ASSIST SWITCH
STEERING SWITCHES
STOP/START OFF SWITCH
W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER
W/ MOONROOF
W/ TELEMATICS
W/O BOSE AUDIO SYSTEM
W/O MOONROOF
WIRELESS CHARGER UNIT
Go to component -> 1.5l turbo, ground distribution circuit (4 of 5) -> RIGHT INSTRUMENT PANEL SPEAKER SHIELD
