Nissan Rogue III (2020-2024) push btn ign sw Wiring diagrams

BACK DR REQ SW BATT PWR SUPLY BLK WIRE BLU WIRE BUZZER CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 21 FUSE 44 FUSE 53 FUSE 6 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED ILLUMINATION PWR SUPLY INSIDE KEY ANTENNA (+) INTELLIGENT KEY UNIT (RIGHT SIDE OF DASH) INTELLIGENT KEY WARNING BUZZER LEFT REAR DOOR OUTSIDE KEY ANTENNA LEFT REAR DOOR REQUEST SWITCH LH FR DR LR DR LR DR SW LT BLU WIRE LT GRN WIRE N POS OUTSIDE KEY ANTENNA (REAR BUMPER) PNK WIRE PPL PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/YEL WIRE PUSH BTN IGN SW RED WIRE RH DR SW RIGHT REAR DOOR RIGHT REAR DOOR OUTSIDE KEY ANTENNA RIGHT REAR DOOR REQUEST SWITCH RR DR - RR DR SW TAN WIRE TCM (TRANSMISSION CONTROL MODULE) TRANSMISSION RANGE SWITCH WHT WIRE YEL WIRE

BACK DR REQ SW BATT PWR SUPLY BLK WIRE BLU WIRE BUZZER CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 21 FUSE 44 FUSE 53 FUSE 6 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED ILLUMINATION PWR SUPLY INSIDE KEY ANTENNA (+) INTELLIGENT KEY UNIT (RIGHT SIDE OF DASH) INTELLIGENT KEY WARNING BUZZER LEFT REAR DOOR OUTSIDE KEY ANTENNA LEFT REAR DOOR REQUEST SWITCH LH FR DR LR DR LR DR SW LT BLU WIRE LT GRN WIRE N POS OUTSIDE KEY ANTENNA (REAR BUMPER) PNK WIRE PPL PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/YEL WIRE PUSH BTN IGN SW RED WIRE RH DR SW RIGHT REAR DOOR RIGHT REAR DOOR OUTSIDE KEY ANTENNA RIGHT REAR DOOR REQUEST SWITCH RR DR - RR DR SW TAN WIRE TCM (TRANSMISSION CONTROL MODULE) TRANSMISSION RANGE SWITCH WHT WIRE YEL WIRE
