Nissan Rogue III (2020-2024) left reclining motor Wiring diagrams
This page contains all the electrical diagrams for the component. left reclining motor, in which he is found in the car Nissan Rogue III (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left reclining motor (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BWD
CAN-H
COMPUTER DATA LINES SYSTEM
DRIVER SEAT CONTROL UNIT
DWN
FUSE 26
FUSE 54
FUSE BLOCK (J/B)
GRN WIRE
GROUND
GRY WIRE
HALL EFFECT SENSOR
HALL EFFECT SENSOR + HALL EFFECT SENSOR +
HOT AT ALL TIMES
LEFT LIFTING MOTOR
LEFT POWER SEAT SWITCH
LEFT RECLINING MOTOR
LEFT SLIDING MOTOR
LEFT THIGH SUPPORT MOTOR
LIFTING MOTOR (DOWNWARD)
LIFTING MOTOR (UPWARD
LT BLU WIRE
LT GRN WIRE
MEM IND 1
MEM IND 2
MEM SW 1
MEM SW 2
MEMORY IND 1
MEMORY INDICATOR-2 CAN-L
MEMORY SW-1
MEMORY SW-2
PNK WIRE
POWER SUPPLY
PPL
PPL/GRY WIRE
PPL/PNK WIRE
RECLINER MOTOR (BACKWARD)
RECLINING MOTOR (FORWARD) BATTERY
RECLINING SWITCH
RED WIRE
SEAT MEMORY SWITCH
SET SW
SLIDE / LIFTING SW
SLIDE MTR (BACKWARD)
SLIDE MTR (FORWARD)
SWITCH GROUND SENSOR GROUND
THIGH SUPPORT MOTOR (DOWNWARD)
THIGH SUPPORT MOTOR (UPWARD)
THIGH SUPPORT SWITCH
WHT WIRE
YEL WIRE
Go to component -> Memory seat circuit -> LEFT RECLINING MOTOR
Wiring diagram left reclining motor (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BWD
BWD FWD
DOWN
DWN
FUSE 54
FUSE 57
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT LIFTING MOTOR
LEFT POWER SEAT SWITCH
LEFT RECLINING MOTOR
LEFT SLIDING MOTOR
LEFT THIGH SUPPORT MOTOR
LIFTING SWITCH
LT BLU WIRE
PNK WIRE
PPL
RECLINING SWITCH
RED WIRE
RIGHT POWER SEAT SWITCH
RIGHT RECLINING MOTOR
RIGHT SLIDING MOTOR
SLIDING SWITCH
THIGH SUPPORT SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power seat circuit -> LEFT RECLINING MOTOR
