Nissan Rogue III (2020-2024) fuel level sensor unit/ fuel pump, fpcm Wiring diagrams
This page contains all the electrical diagrams for the component. fuel level sensor unit/ fuel pump, fpcm, in which he is found in the car Nissan Rogue III (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
fuel level sensor unit/ fuel pump, fpcm wiring diagram (1 of 2)
ADAS CONTROL UNIT 2
AROUND VIEW MONITOR CONTROL UNIT
AWD CONTROL UNIT
BLK WIRE
BRN WIRE
CHASSIS CONTROL MODULE
DISTANCE SENSOR
FUEL LEVEL SENSOR UNIT/ FUEL PUMP, FPCM
HANDS FREE SENSOR CONTROL UNIT
LEFT FRONT SEAT BELT BUCKLE SWITCH
LEFT SIDE RADAR
NCA WIRE
OCCUPANT DETECTION SYSTEM CONTROL UNIT
PASSENGER DOOR MIRROR CONTROL MODULE
PASSENGER SIDE FRONT POWER WINDOW SWITCH
PNK WIRE
PPL/BLK WIRE
RIGHT DOOR LOCK/ UNLOCK SWITCH
RIGHT DOOR MIRROR
RIGHT FRONT DOOR LOCK ASSEMBLY
RIGHT FRONT DOOR REQUEST SWITCH
RIGHT FRONT SEAT HEATER
RIGHT POWER SEAT SWITCH
RIGHT REAR COMBINATION LAMP (BODY SIDE)
RIGHT REAR DOOR LOCK ASSEMBLY
RIGHT REAR DOOR REQUEST SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT SIDE RADAR
RIGHT, CENTER REAR SEAT BELT BUCKLE SWITCH
SONAR CONTROL UNIT
TRANSFER OIL TEMPERATURE SENSOR
W/ HEATED SEATS
W/ MEMORY
W/O HEATED SEATS
W/O MEMORY
Go to component -> 1.5l turbo, ground distribution circuit (1 of 5) -> FUEL LEVEL SENSOR UNIT/ FUEL PUMP, FPCM
fuel level sensor unit/ fuel pump, fpcm wiring diagram (2 of 2)
ABS IND.
AEB OFF IND
AIR BAG IND
AMBIENT SENSOR
BELT IND
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BSW WARNING IND
BUZZER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
E-PARK BRAKE IND
EPS IND
FOG LIGHT IND
FUEL GAUGE
FUEL LEVEL SENSOR UNIT (SUB)
FUEL LEVEL SENSOR UNIT, FUEL PUMP
FUEL LEVEL SENSOR UNIT/ FUEL PUMP, FPCM
FUSE 15
FUSE 29
FUSE 40
FUSE 6
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HI BEAM (BLUE) IND
HIGH BEAM ASSIST (GREEN) IND
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY 1 ENERGIZED
LIGHT (GREEN) IND
LT BLU WIRE
MALFUNCTION IND LAMP (MIL)
MASTER WARNING IND (RED/YELLOW) WIRE
METER ILLUMINATION IND
METER SPEAKER
OIL LEVEL IND
OIL PRESSURE IND
PNK WIRE
POSITION LIGHT (GREEN) IND
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
REAR AEB OFF IND
RED WIRE
SHIELD
SLIP IND
SOUND SYSTEMS
SPEEDOMETER
TACHOMETER
TAN WIRE
TIRE PRESSURE IND
TURN LH IND
TURN RH IND
UNIFIED METER CONTROL UNIT
VDC OFF IND
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WASHER FLUID LEVEL SWITCH
WATER TEMPERATURE GAUGE
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> FUEL LEVEL SENSOR UNIT/ FUEL PUMP, FPCM
