Nissan Rogue III (2020-2024) exhaust valve timing intermediate Wiring diagram

BLK WIRE BLU WIRE BRN WIRE CAMSHAFT POSITION SENSOR COMBINATION METER COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE CONTROL VALVE MOTOR (CLOSE) CONTROL VALVE MOTOR (OPEN) COOLANT TEMPERATURE SENSOR ECM (LEFT SIDE OF ENGINE COMPT) EGR TEMPERATURE SENSOR EGR VOLUME CONTROL VALVE (-) ENGINE COOLANT TEMPERATURE ENGINE COOLANT TEMPERATURE SENSOR 2 ENGINE OIL PRESSURE CONTROL SOLENOID VALVE ENGINE OIL PRESSURE SENSOR ENGINE OIL TEMPERATURE SENSOR EVAP CANISTER PURGE VOLUME EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE EXHAUST GAS TEMPERATURE SENSOR EXHAUST VALVE TIMING CONTROL EXHAUST VALVE TIMING CONTROL SOLENOID VALVE EXHAUST VALVE TIMING INTERMEDIATE EXHAUST VALVE TIMING INTERMEDIATE LOCK CONTROL SOLENOID VALVE FUSE 29 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HEATED OXYGEN SENSOR 2 HOT AT ALL TIMES INTAKE CAMSHAFT POSITION INTAKE CAMSHAFT POSITION SENSOR INTAKE MANIFOLD RUNNER LOCK CONTROL SOLENOID VALVE LT BLU WIRE LT GRN WIRE MALFUNCTION INDICATOR LAMP (MIL) MANIFOLD ABSOLUTE PRESSURE SENSOR PNK WIRE POSITION SENSOR PPL PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/RED WIRE PPL/WHT WIRE PPL/YEL WIRE PRESSURE SENSOR PRESSURE SENSOR, EGR DIFFERENTIAL SENSOR GROUND (MANIFOLD ABSOLUTE RED WIRE SENSOR SENSOR (ELECTRIC INTAKE VALVE SENSOR GND (CRANKSHAFT SENSOR GND (ENGINE SENSOR GND (ENGINE OIL SENSOR GND (EXHAUST SENSOR GND (REFRIGERANT PRESSURE SENSOR) SENSOR GROUND SENSOR GROUND (ADMISSION VALVE, SOLENOID VALVE TAN WIRE TEMPERATURE SENSOR TIMING CONTROL SIGNAL) TURBOCHARGER BOOST SENSOR, ENGINE OIL TURBOCHARGER BYPASS CONTROL VALVE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE
