Nissan Rogue III (2020-2024) ect sens 2 Wiring diagrams

This page contains all the electrical diagrams for the component. ect sens 2, in which he is found in the car Nissan Rogue III (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram ect sens 2 (1 of 3)

Wiring diagram ect sens 2 for Nissan Rogue III (2020-2024) (1 of 3)

Get access

BATT PWR SPLY BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM COOLING FAN CONTROL MODULE 1 COOLING FAN CONTROL MODULE 2 COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 ECM GND ECT SENS 1 ECT SENS 2 ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 FUSE 100 FUSE, FUSIBLE LINK BOX 2 FUSIBLE LINK V FUSIBLE LINK X GRN WIRE GRY WIRE HOT AT ALL TIMES LT GRN WIRE NCA WIRE PRESS SENS PWM PWR PWM SIG RED WIRE REFRIGERANT PRESS SENS REFRIGERANT PRESSURE SENSOR SENS GND SENS PWR SPLY SENS PWR SUPPLY TAN WIRE WHT WIRE

Go to component -> 1.5l turbo, automatic a/c circuit (4 of 4) -> ECT SENS 2

Wiring diagram ect sens 2 (2 of 3)

Wiring diagram ect sens 2 for Nissan Rogue III (2020-2024) (2 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM COOLING FAN CONTROL MODULE 1 COOLING FAN CONTROL MODULE 2 COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 ECM GND ECT SENS 1 ECT SENS 2 ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 FUSE, FUSIBLE LINK BOX 2 FUSIBLE LINK V FUSIBLE LINK X GRN WIRE GRY WIRE HOT AT ALL TIMES IGNITION RELAY IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT GRN WIRE MOD CONT NCA WIRE PNK WIRE PRESS SENS PWM PWR PWM SIG RED WIRE REFRIGERANT PRESS SENS REFRIGERANT PRESSURE SENSOR SENS GND SENS PWR SPLY SMART FET WHT WIRE

Go to component -> 1.5l turbo, cooling fan circuit -> ECT SENS 2
