Nissan Rogue III (2020-2024) door open sw Wiring diagram
This page shows the only wiring diagram for the component.door open sw, which is found in the car Nissan Rogue III (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door open sw (1 of 1)
AUTOMATIC BACK DOOR WARNING BUZZER
BACK DOOR OPENER SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
DOOR OPEN SW
DOOR SW
FUSE 15
FUSE 26
FUSE BLOCK (J/B)
FUSIBLE LINK JJ
GRN WIRE
HOT AT ALL TIMES
INTELLIGENT KEY UNIT
LEFT SPINDLE UNIT (TOP OF LEFT "D" PILLAR)
LEFT TOUCH SENSOR
LIN COMMUNICATION
LT GRN WIRE
OPENER SWITCH
PNK REQ SW WIRE
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/PNK CAN-L WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/TAN WIRE
PPL/YEL WIRE
REQUEST SWITCH
RIGHT SPINDLE UNIT
SENS GND
SHIELD
TAN WIRE
TOUCH SENS
WHT WIRE
YEL WIRE
Go to component -> Back door opener circuit, w/ automatic back door system (2 of 2) -> DOOR OPEN SW
