Nissan Rogue III (2020-2024) combi sw in 6 Wiring diagrams
This page contains all the electrical diagrams for the component. combi sw in 6, in which he is found in the car Nissan Rogue III (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
combi sw in 6 wiring diagram (1 of 2)
BATTERY POWER SUPPLY (FUSE) BATT BCM FUSE
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBI SW IN 1
COMBI SW IN 2
COMBI SW IN 3
COMBI SW IN 4
COMBI SW IN 5
COMBI SW IN 6
COMBI SW OUT 1
COMBI SW OUT 2
COMBI SW OUT 3
COMBI SW OUT 4
COMBI SW OUT 5
COMBI SW OUT 6
COMBINATION METER
COMBINATION SWITCH (WIPER, WASHER SWITCH)
COMPUTER DATA LINES SYSTEM
EXTENDED STORAGE FUSE SWITCH
FUSE 15
FUSE 30
FUSE 56
FUSE 6
FUSE BLOCK (J/B)
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL/BLU WIRE
PPL/BRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WHT WIRE
YEL WIRE
Go to component -> Front wiper/washer circuit (1 of 2) -> COMBI SW IN 6
combi sw in 6 wiring diagram (2 of 2)
BATTERY POWER SUPPLY (FUSE) BATT BCM FUSE
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBI SW IN 1
COMBI SW IN 2
COMBI SW IN 3
COMBI SW IN 4
COMBI SW IN 5
COMBI SW IN 6
COMBI SW OUT 1
COMBI SW OUT 2
COMBI SW OUT 3
COMBI SW OUT 4
COMBI SW OUT 5
COMBI SW OUT 6
COMBINATION METER
COMBINATION SWITCH (WIPER, WASHER SWITCH)
COMPUTER DATA LINES SYSTEM
EXTENDED STORAGE FUSE SWITCH
FRONT WASHER PUMP RELAY
FRONT, REAR WASHER PUMP
FRONT, REAR WASHER PUMP RELAY
FUSE 15
FUSE 30
FUSE 56
FUSE 6
FUSE 81
FUSE BLOCK (J/B)
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
IGNITION RELAY
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
REAR WASHER PUMP RELAY
REAR WIPER MOTOR
REAR WIPER MOTOR (CENTER OF BACK DOOR)
REAR WIPER STOP POSITION
RED WIRE
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WASHER FLUID LEVEL SWITCH
WHT WIRE
YEL WIRE
Go to component -> Rear wiper/washer circuit -> COMBI SW IN 6
