Car Wiring Diagrams for Starting circuit, w/ intelligent key for Nissan Rogue II facelift (2016-2020)

ACC/ON BATTERY BCM (BODY CONTROL MODULE) BLK WIRE BLK/RED WIRE BLU WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM ECM (2.5L) EXCEPT HYBRID HYBRID FUSE 46 FUSE, FUSIBLE LINK, RELAY BOX 1 FUSIBLE LINK A FUSIBLE LINK B FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK C FUSIBLE LINK M GENERATOR GRN WIRE GRY WIRE HIGH VOLTAGE FUSE, FUSIBLE LINK, RELAY BOX HPCM (2.0L HYBRID) I START WO ESCL SW IGNITION RELAY 1 IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT BLU WIRE NCA WIRE O START SW BACKLIGHT LED O STCUT RL P/N SIG PNK WIRE PNP SIG PUSH PUSH BUTTON IGNITION SWITCH STARTER CUT RELAY STARTER MOTOR STARTER RELAY SWITCH TAN WIRE TRANSMISSION RANGE SWITCH WHT WIRE YEL WIRE
