Nissan Rogue II facelift (2016-2020) Wiring diagram engine performance 2.0l hybrid, virtual engine sound system circuit

APPROACHING VEHICLE SOUND FOR PEDESTRIANS (VSP) CONTROL UNIT BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM FUSE 13 FUSE 31 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IGN LT GRN WIRE PNK WIRE PPL RIGHT END OF DASH) UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) VDC OFF IND
