Nissan Rogue II facelift (2016-2020) ses ext left ant b Wiring diagram

ACC/ON AT LOCKED IN PARK SW BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE BUZZER CAN L CAN-H CAN-H (OR PPL) SES EXT REAR ANT B COMBINATION METER COMPUTER DATA COMPUTER DATA LINES SYSTEM CVT SHIFT SELECTOR EXCEPT HYBRID FUSE 10 FUSE 13 FUSE 31 FUSE 46 FUSE 7 FUSE BLOCK (J/B) (LEFT END OF DASH) FUSE, FUSIBLE LINK, RELAY BOX 1 FUSIBLE LINK M GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START HPCM (HYBRID) (LEFT SIDE OF DASH) IGNITION RELAY 2 INSIDE KEY ANTENNA (CONSOLE) IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LEFT FRONT DOOR SWITCH LEFT FRONT OUTSIDE HANDLE ASSEMBLY LEFT REAR DOOR SWITCH LINES SYSTEM LT BLU WIRE LT GRN WIRE OUTSIDE KEY ANTENNA OUTSIDE KEY ANTENNA (REAR BUMPER) P/N SIG PARK POSITION SWITCH PNK SES EXT RIGHT ANT A WIRE PNK WIRE PPL PPL SES EXT LEFT ANT A PPL/GRN WIRE PUSH BUTTON IGNITION SWITCH PUSH SWITCH PWR ATDVC PWR ECU RED WIRE RIGHT END OF DASH) RIGHT FRONT DOOR SWITCH RIGHT FRONT OUTSIDE HANDLE ASSEMBLY RIGHT REAR DOOR SWITCH RL DOOR SW RR DOOR SW SECURITY IND SECURITY LED SES EXT LEFT ANT B SES EXT REAR ANT A PNK CAN-L WIRE SES EXT RIGHT ANT B SES INT MIDDLE ANT B SES INT MIDDLE ANT A START SW BACK LIGHT LED START WO ESCL SW STARTER CUT RELAY STARTER RELAY STARTING/CHARGING SYSTEM STCUT RL STOP LAMP SW STOP LAMP SWITCH TAN WIRE TRANSMISSION RANGE SWITCH UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE YEL WIRE
